Surfacing


SURFACING AND MACHINING FLAME CUT PLATES



The OXYMETAL Group is equipped with machines for surfacing and machining flame cut parts of large dimensions to fulfil the requirements of its customers such as press toolmakers.







SPECIFICS

Flame cutting and machining of plates for: press toolmaking, mechanical toolmaking, general mechanics, building and civil works, special machines, agricultural machinery, metallic architecture

Pre-machined plates: rough or milled edges, rough or machined sides

Machining: drilling (dia. 6 to 50mm) – Tapping (M6 to M32) – Surfacing

Precision of surfacing: 0.1mm/m, Parallelism 0.15mm/m, Roughness Ra included between 1.6 and 3.2,



APPLICATIONS

Types of materials: Common construction steels, anti-abrasion steels, HLE steel, etc.

Thickness: From 6 to 260mm

Levelling: 600 tonnes hydraulic press of +/-1.5mm per metre for thickness less than 100mm, +/-2mm per metre for thickness greater than 100mm



EQUIPMENT

Machine fleet: Milling machines, 3 axes with gantry, maximum capacity 8,000 x 2,500 x 800
